FLEXBUS RAIN RFID READER
FLEXRFID
Model: FBRFID-A
The FLEXBUS RFID READER allows easy aggregation of sensor data for railroad wayside FLEXBUS sensors onto the FLEXBUS network. Just another logical step to make sensor and RFID integration seamless and easy.
The FLEXRFID reader provides dual RFID scanners based on the popular industrial RAIN RFID standard for the EPC UHF Gen 2 protocol, providing a cost effective solution for commuter or freight rail systems.
Size (L x W x H) 128 x128 × 32 mm
FLEXBUS EXPANDER
FLEXEXPANDER
Model: FBEXP-A
The FLEXBUS EXPANDER allows for easy integration of railroad wayside FLEXBUS sensors onto the FLEXBUS network. The passive expander allows seamless combinations of star and bus cable topologies for easy cable management..
The FLEXBUS expander act as a first line of defense when faced with FLEXBUS network cable distribution issues.
Size (L x W x H) 136 x28 × 24 mm
RT3000 FLEXBUS SPLITTER
FLEXSPLITTER
Model: FLEXSPL-A
The FLEXBUS SPLITTER allows the railroad wayside FLEXBUS to be extended to virtually infinite cable lengths. The active FLEXBUS SPLITTER allows seamless combinations of star and bus cable topologies - no need to worry about bus noise and the so called impedance mismatches and bus terminations associated with long cables - we have you covered.
The FLEXBUS Splitter has a built-in web GUI allowing communications setup and real-time viewing of event messages transmitted by sensors on the FlexBus network with active bus termination control. The FLEXBUS SPLITTER include two independent active split HUB extensions.
Size (L x W x H) 128 x128 × 32 mm
RT3000 FLEXBUS NETWORK HUB
FLEXHUB
Model: FLEXHUB-A
FLEXHUB allows customers to have direct access to the railroad wayside FlexBus sensor event message stream in real-time via WiFi TCP/IP or serial RS232 or RS485.
The FLEXHUB has a built-in web GUI allowing communications setup and real-time viewing of event messages transmitted by sensors on the FlexBus network. The FLEXHUB allows system integrators to perform real-time integration into custom embedded systems tailored to their own requirements. The FLEXHUB accommodates two axle counters and ensures synchronous time stamping of event messages with the correct axle counter values if so required.
Size (L x W x H) 96 x132 × 32 mm
All Weather Smart Optical Sensor
SMART OPTICAL RAIL CAR COUNTER
LIDX-A
Model: LIDX-A All Weather Smart Optical Sensor
LIDX-A is a programmable long distance laser based sensor for train detection, rail car counting or axle counting as well as train speed calculation
LIDX-A Smart distance optical sensor can measure and count rail cars, wheel axles or train speed with built-in web GUI. Can measure from a safe distance as far as 50 meters away.
Size (L x W x H) 180 × 96 × 65 mm
WiFi GUI
All Weather Thermal Sensor
THERMAL WHEEL BEARING SENSOR THUX-A
Model: THUX-A All Weather Thermal Smart Sensor
A snow storm covered your thermal sensor - and now you missed that hot wheel - not with our All Weather THUX thermal sensor.
THUX-A RAILFL≡X All weather high speed IR wheel hot bearing or hotbox temperature sensor with 16 programmable trigger zones. Works in networked or stand alone mode way side scanning of wheel temperatures with built-in web GUI.
Size (L x W x H) 180 × 96 × 65 mm
WiFi GUI
SPECIFICATIONS
User Interface | WiFi GUI with 16 Programmable set point temperatures. | |
Model THUX-A | THUX-A Hot Box wheel Bearing sensing with 16 programmable temperature set points | |
Spectral Range Focal Length | 10x10 @ 150cm 7.5-14 µm IR | |
Mounting | Rail wayside Vertical mount above ground | |
Digital Output Purpose | Event Trigger | |
Accuracy | Accuracy ±5°C @ 1KHz sampling rate subject to scan speed | |
External Power Operation | 24 V DC 1 W max | |
Setpoints | 16 programmable spotmeters boxes per zone | |
Housing material | Polyamide Carbon
| |
Digital Processing | Quad Core ARM | |
Power Consumption | 1 W at 24 V DC typical | |
Power Connection | M12 8-pin | |
Thermal scan rate | 1000 Hz | |
Radio Spectrum | • FCC 47 CFR Part 15 Class C (2.4 GHz band US) • ETSI EN 300 328 V2.1.1 (2.4 GHz band EU) | |
Connector Type | M12 8-pin | |
Weight | 510g (1.11lb) | |
Vibration | IEC 60068-2-6 | |
Thermal Sensitivity | <35mK | |
Web interface | Yes WiFi | |
Corrosion | ISO 12944 C4 G | |
IR Resolution | 16 programmable temperature set points per zone
| |
Shock | IEC 60068-2-27 | |
Size (L x W x H) | 97 × 64 × 182 mm | |
Operating Temperature Range | –20 to 50°C : 70°C (158°F)
| |
Base Mount | 2x M10 Bolts
| |
Encapsulation | IEC 60529 and IP66 | |
Capabilities | All Weather Programmable Temperature sensor for Hot Wheel - Hot Box over temperature detection. |
WIPD RT3000 Edge Processor
WIPD RT3000 Edge Processor
Model: WE000A Edge Message Processor(Advanced)
RT3000 Edge message processor facilitates event message routing from our smart wayside rail sensors. Also included are 4x powerful programmable message processors for things such as RFID readers, modems to name just a few. With dedicated WiFI socket servers to connect directly to computers, the internet or via cellular modems to central servers for easy compact data routing, Built-in automated email error log report forwarding to multiple recipients via LTE or WiFi out of the box. The RT3000 Edge Processor allow system integrators to quickly integrate a complex array of sensors maximize uptime, and minimize maintenance costs.
SPECIFICATIONS - WE000A
WiFi GUI
Communications | 3x FlexBUS ports ; 4 x Programmable message channels with RS232/RS485/WiFi options
|
Ethernet Interface | Wi-Fi GUI |
Digital Inputs | 2x opto-isolated, 3–25 V Wheel Counters |
File Storage | FAT32 MicroSD card data storage (Customizable Scripting) 32GByte
|
Digital Output Purpose | 1x External Event Trigger Digital Output |
Humidity (Operating and Storage) | IEC 60068-2-30/24 hours, 95% relative humidity, 25–40°C (77–104°F)/2 cycles EN60068-2-38
|
External Power Operation | 24/32 V DC 8 W max |
External Voltage | Allowed range 18–32 V DC |
Housing material | High Impact Carbon Polyamide
|
Digital I/O isolation voltage | 500 VRMS |
RS-232 | 4x RS232 programmable C string manipulation) |
RS-485 | 4x RS485 programmable C string manipulation) Half/Full Duplex |
Power Connection | M12 8-pin Female (shared with Digital I/O) |
Digital Outputs | External Trigger 1x opto-isolated, 0–48 V DC |
Connector Type | 8x M12 8-pin, female
|
Axle counters | 2x Programmable axle counter inputs |
Weight | 519g (1.14lb) |
TCP/IP Socket Servers | 2x Dedicated Messaging WiFi TCP/IP socket servers |
Base Mount | 4 x M6/7 |
Corrosion | • ISO 12944 C4 G or H • EN60068-2-11 |
Sensor Support | 3x RailFlex Bus M12 8-pin suppurts up to 32 RailFlex sensors |
Shock | IEC 60068-2-27, 25 g |
Size (L x W x H) | 250 × 192 × 50 mm |
Operating Temperature Range | –20 to 50°C (–4 to 122°F)
|
Ethernet Communication | TCP/IP socket-based ASCII |
EMC | EN 61000-4-8 (magnetic field) • FCC 47 CFR Part 15 Class B (emission ) |
Digital input purpose | Axle Counter Inputs (2x)
|
Encapsulation | IEC 60529 and IP66 |
SPECIFICATIONS
RT3000 GUI Display
RT3000 GUI
WEB Display
Model: RT3000GUI
RT3000 GUI Panel mount 10" WEB display provides onsite real-time viewing of event data and setup information using our intuitive browser based touch screen display interface with magnetic removable base and swivel tilt control for tight spaces.
WiFi GUI
SPECIFICATIONS - RT3000GUI
Display | 7" Color Touch Screen
|
Ethernet Interface | Wi-Fi |
External Power Operation | 24/48 V DC 8 W max |
Storage | NA |
Housing material | PA12 |
Cut-out | 232x123mm |
Power Consumption | • 7.5 W at 24 V DC typical |
Weight | 800g (1.74lb) |
Web interface | Yes |
Corrosion | • ISO 12944 C4 G or H • EN60068-2-11 |
Size (L x W x H) | 265 × 143 x 53 mm |
Operating Temperature Range | –10 to 50°C
|
Base Mounting | 6x M4 |
WILD Train Wheel Wayside sensor
WILD WSOOA SENSOR
Model: WSOOA Bolt-on WILD Sensor
Model: WSOOAM Magnetic Mount WILD Sensor
WS00A WILD RAILFL≡X sensor is part of the WILD wheel impact processor of which two WSOOA smart sensors are used per rail.
Offered in either permanent bolt-on or quick release magnetic mount.
SPECIFICATIONS - WS00A
Base Mounting | 3 x M10 Bolts
|
Ethernet Interface | Wi-Fi GUI |
Digital Inputs | 2x opto-isolated, 3–25 V |
Digital I/O connector type | M12
|
Digital Output Purpose | Event Trigger (NC) |
Humidity (Operating and Storage) | IEC 60068-2-30/24 hours, 95% relative humidity, 25–40°C (77–104°F)/2 cycles EN60068-2-38
|
External Power Operation | 24/48 V DC 8 W max |
External Voltage | Allowed range 18–56 V DC |
Housing material | High Impact Carbon Polyamide
|
Digital I/O isolation voltage | 500 VRMS |
Power Consumption | • 7.5 W at 24 V DC typical |
Power Connection | M12 12-pin A-coded, male (shared with Digital I/O) |
Digital Outputs | External Trigger 1x opto-isolated, 0–48 V DC |
Connector Type | M12 8-pin X-coded, female; RP-SMA, female
|
Weight | 519g (1.14lb) |
Digital Outputs | 3x opto-isolated, 0–48 V DC, max. 350 mA; solid-state opto relay; 1x dedicated as Fault output (NC) |
Web interface | Yes |
Digital Inputs | 2x opto-isolated, Vin(low)= 0–1.5 V, Vin(high)= 3–25 V |
Shock | IEC 60068-2-27, 25 g |
Size (L x W x H) | 281 × 52 × 99 mm |
Operating Temperature Range | –20 to 50°C (–4 to 122°F)
|
EMC | EN 61000-4-8 (magnetic field) • FCC 47 CFR Part 15 Class B (emission ) |
Digital input purpose | Axle Counter Inputs (2x)
|
Encapsulation | IEC 60529 and IP66 |
WS00A WP3000 WILD PROCESSOR WS00A
WS00A
WS00A-M
WS00A-M8
SPECIFICATIONS
WS00A WP00A WS00A
WILD Train Wheel Wayside Processor
WILD WP3000
Processor
Model: WP3000
WP3000 WILD RAILFL≡X processor is part of the WIPD wheel impact system of which two WSOOA smart sensors are used per rail. Intuitive easy to use WiFi web GUI setup.
SPECIFICATIONS - WP3000
Capabilities | On Rail Wheel impact Processor (2x WS00A sensors) |
GUI Interface | Wi-Fi GUI |
I/O connector type | M12 8-pin |
Humidity (Operating and Storage) | IEC 60068-2-30/24 hours, 95% relative humidity, 25–40°C (77–104°F)/2 cycles EN60068-2-38
|
Power Operation | 24 V DC 1 W max |
External Voltage | 24 V DC |
Housing material | High Impact Carbon Polyamide
|
Digital I/O isolation voltage | 500 VRMS |
Power Connection | M12 8 pin Female |
Signal Sensitivity Range | 0-200g |
Connector Type | M12 8-pin female |
Weight | 739g (1.64lb) |
Digital Outputs | NC |
Web interface | WiFi GUI |
Digital Inputs | NC |
Shock | IEC 60068-2-27 |
Size (L x W x H) | 281 × 55 × 99 mm |
Operating Temperature Range | –40 to 50°C (–4 to 122°F)
|
EMC | EN 61000-4-8 (magnetic field) • FCC 47 CFR Part 15 Class B (emission ) |
Base Mounting | 2x M10 Bolts
|
Encapsulation | IEC 60529 and IP66 |
WS00A WP3000 WS00A
WiFi GUI
Wheel Counter Sensor
WHEEL COUNTER CWOOA SENSOR
Model: CWOOA + Inductive Smart Sensor
CWOOA RAILFL≡X wheel counter sensor. This narrow field sealed inductive sensor are compatible with all RAILFLX sensors and can operate in single or dual directional traffic scenarios
SPECIFICATIONS - CW00A
Base Mounting | 2 x M10 Bolts
|
Digital I/O connector type | M12 8-pin
|
Digital Output Purpose | Rail Car wheel counter interface |
External Power Operation | 24 DC 1 W max |
Housing material | High Impact Carbon Polyamide
|
Rated Switching Distance | 50mm |
Output Type | NPN |
Power Consumption | 0.5 W at 24 V DC typical |
Digital Outputs | NPN Pulse NO contact 3-wire |
Wheel Count Speed | 1kHz |
Weight | 820g (1.84lb) |
Shock | IEC 60068-2-27 |
Size (L x W x H) | 182 × 52 × 99 mm |
Operating Temperature Range | –20 to 50°C (–4 to 122°F)
|
EMC | EN 61000-4-8 (magnetic field) • FCC 47 CFR Part 15 Class B (emission ) |
Encapsulation | IEC 60529 and IP66 |
Optical Dragging Equipment Sensor
DRAG DPOOA
SENSOR
Model: DPOOA + Optical Drag detector Smart Sensor
DPOOA RAILFL≡X sensor pair dragging equipment sensor forms an optical barrior accross and in between rail track consisting of a transmitter and receiver unit pair. The DP00A can work as part of an expanded RAILFLEX sensor array or on its own. Can be configured via a build in web user interface and accepts two wheel counter inputs with parameter settings..
SPECIFICATIONS - DP00A
WiFi GUI
Base Mounting | 2x M10 Bolts |
Capabilities | Optical Drag detector
|
Ethernet Interface | Wi-Fi GUI |
Digital Inputs | Wheel Counters Optional |
Digital I/O connector type | M12 |
Digital Output Purpose | Event Trigger Output |
Humidity (Operating and Storage) | IEC 60068-2-30 |
External Power Operation | 24V DC 1 W max |
Housing material | High Impact Carbon Polyamide
|
Digital I/O isolation voltage | 500 VRMS |
Power Consumption | • 1.5 W at 24 V DC typical |
Digital Outputs | External Trigger 1x opto-isolated, 0–48 V DC |
Connector Type | M12 8-pin |
Weight | 685g (1.34lb) |
Web interface | Yes WiFi |
Shock | IEC 60068-2-27 |
Size (L x W x H) | 261 × 52 × 99 mm |
Operating Temperature Range | –20 to 50°C (–4 to 122°F)
|
EMC | EN 61000-4-8 |
Digital input purpose | Axle Counter Inputs (2x)
|
Encapsulation | IEC 60529 and IP66 |
Wheel Load Sensor
LOAD SENSOR
LSOOA
Model: LSOOA Smart Sensor
LSOOA RAILFL≡X sensor pair can be configured to measure load imbalance or axle misalignment conditions. The LSOOA can work as part of an expanded RAILFLEX sensor array or on its own. Can be configured via a build in web user interface and accepts two wheel counter inputs with parameter settings..
SPECIFICATIONS - LS00A
WiFi GUI
Base Mounting | 3x M10 Bolts |
Base Mounting | 3 x M10 Bolts
|
Ethernet Interface | Wi-Fi GUI |
Digital Inputs | 2x opto-isolated, 3–25 V Axle Counters |
Digital I/O connector type | M12 8-pin |
Digital Output Purpose | Event Trigger Output |
External Power Operation | 24 V DC 1 W max |
Housing material | High Impact Carbon Polyamide
|
Digital I/O isolation voltage | 500 VRMS |
Power Consumption | • 1.5 W at 24 V DC typical |
Digital Outputs | External Trigger 1x opto-isolated, 0–48 V DC |
Weight | 802g (1.54lb) |
Web interface | Yes WiFi |
Digital Inputs | 2x opto-isolated, Wheel Counter Interface |
Shock | IEC 60068-2-27 |
Size (L x W x H) | 358 × 52× 99 mm |
Operating Temperature Range | –20 to 50°C (–4 to 122°F)
|
EMC | EN 61000-4-8 |
Digital input purpose | Axle Counter Inputs (2x)
|
Encapsulation | IEC 60529 and IP66 |
Cable Management Adjustable Cover guard
FLEX GUARD
CM5OO-D
Model: CM5OO-D
CM5OO-D RAILFL≡X adjustable cable management for flex sensor cable guard protects sensor cables. compatible for integration with RAILFL≡X sensors.. High Impact Polyamide. Cable entry to 1 inch flexible conduit tubing
Size (L x W x H) adj [ 62-92 ] × 52× 99 mm
Cable Management Adjustable Cover guard
FLEX GUARD
CM5OO-C
Model: CM5OO-C
CM5OO-C RAILFL≡X adjustable cable management for flex sensor cable guard protects sensor cables. compatible for integration with RAILFL≡X sensors.. High Impact Polyamide. Cable entry to 1 inch flexible conduit tubing
Size (L x W x H) adj [ 100-164 ] × 52× 99 mm
Cable Management Cover guard
FLEX GUARD
CMOOF
Model: CMOOF
CMOOF RAILFL≡X cable management for flex sensor entry or exit cable guard protects sensor cables. compatible for integration with RAILFL≡X sensors.. High Impact Polyamide. Cable entry to 1 inch flexible conduit tubing
Size (L x W x H) 128 × 52× 99 mm
Cable Management Cover guard
FLEX GUARD
CMOOC
Model: CMOOC
CMOOC RAILFL≡X cable management for flex sensor entry or exit cable guard protects sensor cables. compatible for integration with RAILFL≡X sensors.. High Impact Polyamide. Cable entry to 1 inch flexible conduit tubing. Cable entry to 1 inch flexible conduit tubing
Size (L x W x H) 128 × 52× 99 mm
Cable Management Cover guard
FLEX GUARD
CMOOB
Model: CMOOB
CMOOB RAILFL≡X cable management for flex sensor entry or exit cable guard protects sensor cables. compatible for integration with RAILFL≡X sensors.. High Impact Polyamide. Cable entry to 1 inch flexible conduit tubing. Cable entry to 1 inch flexible conduit tubing
Size (L x W x H) 330 × 52× 99 mm
Cable Management Adjustable Cover guard
FLEX GUARD
CM5OO-B
Model: CM5OO-B
CM5OO-B RAILFL≡X adjustable cable management for flex sensor cable guard protects sensor cables. compatible for integration with RAILFL≡X sensors.. High Impact Polyamide. Cable entry to 1 inch flexible conduit tubing
Size (L x W x H) adj [ 180-320 ] × 52× 99 mm
Cable Management Adjustable Cover guard
FLEX GUARD
CM5OO-A
Model: CM5OO-A
CM5OO-A RAILFL≡X adjustable cable management for flex sensor cable guard protects sensor cables. compatible for integration with RAILFL≡X sensors.. High Impact Polyamide. Cable entry to 1 inch flexible conduit tubing
Size (L x W x H) adj [ 337-626 ] × 52× 99 mm
Cable Management Adjustable Cover guard
FLEX GUARD
CM5OO-E
Model: CM5OO-E
CM5OO-E RAILFL≡X adjustable cable management for flex sensor cable guard protects sensor cables. compatible for integration with RAILFL≡X sensors.. High Impact Polyamide. Cable entry to 1 inch flexible conduit tubing
Size (L x W x H) adj [ 376-646 ] × 52× 99 mm
Cable Management Cover guard
FLEX GUARD
CM003
Model: CMOO3
CM003 RAILFL≡X cable management for flex sensor cable guard protects sensor cables. compatible for integration with RAILFL≡X sensors.. High Impact Polyamide. Cable entry to 1 inch flexible conduit tubing
Size (L x W x H) 40 × 52× 99 mm
Cable Management Cover guard
FLEX GUARD
CM004
Model: CMOO4
CM004 RAILFL≡X cable management for flex sensor cable guard protects sensor cables. compatible for integration with RAILFL≡X sensors.. High Impact Polyamide. Cable entry to 1 inch flexible conduit tubing
Size (L x W x H) 30 × 52× 99 mm
Cable Management Adjustable Cover guard
FLEX GUARD
CM5OO-F
Model: CM5OO-F
CM5OO-F RAILFL≡X adjustable cable management for flex sensor cable guard protects sensor cables. compatible for integration with RAILFL≡X sensors.. High Impact Polyamide. Cable entry to 1 inch flexible conduit tubing
Size (L x W x H) adj [ 480-650 ] × 52× 99 mm
Cable Management Adjustable Cover guard
FLEX GUARD
CM5OO-G
Model: CM5OO-G
CM5OO-G RAILFL≡X adjustable cable management for flex sensor cable guard protects sensor cables. compatible for integration with RAILFL≡X sensors.. High Impact Polyamide. Cable entry to 1 inch flexible conduit tubing
Size (L x W x H) adj [ 502-650 ] × 52× 99 mm
bottom of page
